Choosing fasteners for automotive assemblies

A fastener is only as good as the joint it holds. On an automotive or pneumatic assembly, the wrong thread form or the wrong finish shows up as a leak, a loosened joint, or a galled thread on the line. Here is how we spec them.

Match the thread to the load

Start with thread form and class: metric or unified, coarse or fine, and the fit class the mating part expects. Fine threads carry more load in a given diameter and resist vibration loosening, which is why they show up on air fittings and adjustment screws. Coarse threads assemble faster and tolerate a rougher bore. Call out the class (6g/6H or 2A/2B) so the part gauges the same every lot.

Material and finish decide the life

Brass seals well and machines clean, which is why most pneumatic fittings are brass. Stainless (303 for free-machining, 304 or 316 for corrosion) goes where the part sees moisture or wash-down. Carbon steel takes a plating. Finish is not cosmetic: black oxide and zinc change corrosion life and thread friction, and passivated stainless resists the rust that seizes a joint.

Do not forget the sealing surface

A fitting that holds pressure needs a flat, burr-free sealing face or a clean groove for the O-ring. We turn the sealing face in the same setup as the thread so it runs concentric. Specify the seal (O-ring size, crush washer, tapered thread) and we cut the seat to match.

When to go custom

Off-the-shelf fasteners cover the common cases. Go custom for a nonstandard length, a combined feature (a stud with an integral flange, a fitting with a barb and a hex in one part), a specific material, or tolerances tighter than a catalog part holds. That is turned work. Send the drawing and we quote it.
